| Material | Aluminium with low content of copper |
| IP Rating | IP65/IP66 |
| Ambient temperature | -20°C to +55°C |
| Approvals | GUMT INERIS 00ATEX0033X GOST R |
| PTA CESI 03 ATEX 101 X |
|
| Marking | GUMT II 2 GD Ex-d IIC T5 Gb Ex-tb IIIC T100°C Db IP66PTA II 2 GD Ex-d IIC T6 Ex-tD A21 IP65 T85°C |
|
Surface treatment Entries Rated nominal current Rated nominal voltage |
Green colour polyurethane painting cycle RAL6003 (other colour available upon request)
n° 3 entries M20x1,5, one complete with brass nickel chrome plated plug 6 mA 0,25 V |
| Changeover contact rating (GUMT) |
5 A |
| Standard certificate label | Made by self adhesive UV and corrosion resistant polyester, approved by INERIS Laboratory. |
| Accessories available upon request |
Cable reel Drain/breather valve Internal anticondensate painting Traffolyte/Stainless steel certificate label |
| Material | Aluminium with low content of copper |
| IP Rating | IP65 |
| Temperature | -20°C to +55°C |
| CESI 03 ATEX 101 X | |
| Approvals | CESI 03 ATEX 101 X |
| Marking | II 2 GD Ex-d IIC T6 Ex-tD A21 IP65 T85°C |
| Nominal current ln
Insulation voltage Accessories available |
10 A
3 kV Cable reel |
| Visual Signals |
|
| Cable Glands |
|
| Plugs&Sockets |
|
| Harmatex Components |
|
| Ex-d components |
|
A place in which an explosive atmosphere consisting of a mixture with air of flammable substances in the form of gas, vapour or mist is present continuosly or for long periods or frequently.
Explosive atmosphere for more than 1000 h/yr.
A place in which an explosive atmosphere consisting of a mixture with air or flammable substances in the form of gas, vapour or mist is likely to occur in normal operation occasionally.
Explosive atmosphere for more than 10, but less than 1000 h/yr.
A place in which an explosive atmosphere consisting of a mixture with air of flammable substances in the form of gas, vapour or mist is not likely to occur in normal operation, but – if it does occur – will persist for a short period only.
Explosive atmosphere for less than 10 h/yr
A place in which an explosive atmospere in the form of cloud of combustible dust in air is present continously, or for long periods or frequently.
A place in which an explosive atmosphere in the form of a cloud of combustible dust in air is likely to occur in normal operation occasionally.
A place in which an explosive atmosphere in the form of a cloud of combustible dust in air is not likely to occur in normal operation, but – if it does occur – will persist for a short period only.
|
ATEX |
OLD Gas Atmosphere |
New IEC 60079-0:2007/EN 60079-0:2009 |
|
II 2 G |
EEx/Ex d IIB T6 |
Ex d IIB T6 Gb or Ex db IIB T6* |
|
II 2(1) G |
EEx/Ex d [ia IIC] IIB T6 |
Ex d [ia IIC Ga] IIB T6 Gb or Ex db [ia IIC] IIB T6* |
|
II 2 G |
EEx/Ex ia IIC T4 |
Ex ia IIC T4 Gb or Ex ib IIC T4* |
|
II 2 G |
EEx/Ex e II T4 |
Ex e IIC T4 Gb or Ex eb IIC T4* |
|
ATEX |
OLD Dust Atmosphere |
New IEC 60079-0:2007/EN 60079-0:2009 |
|
II 2 D |
Ex tD A21 IP65 T120°C |
Ex t IIIC T120°C Db or Ex tb IIIC T120°C* |
|
II 2(1) D |
Ex tD [iaD] A21 IP65 T120°C |
Ex t [ia Da] IIIC T120°C Db or Ex tb [ia] IIIC T120°C* |
|
II 1 D |
Ex isD A20 IP65 T120°C |
Ex ia IIIC T120°C Ga or Ex ia IIIC T120°C* |
